By Steve Miller

Mostly, the images we capture pale in comparison to what we “saw” on the dive. There are a couple exceptions to this, where the camera actually captures more than your naked eye. The most obvious is super macro, when the subject is so small that you can see no detail, but the camera shows you things you never dreamed were there, just like shooting through a microscope. But there is another time where the camera can capture details you didn't necessarily see - it just takes some work. We call this HDR (High Dynamic Range) Photography.

Steve Miller HDR Boat on Water

HDR isn't just for sunsets. Note the definition in both the lightest and darkest parts of this image. © 2022 Steve Miller


The Mechanics of HDR

Your eye can read a scene with harsh light or a wide variance in brightness better than your lens - of course. Expensive cameras can capture a wider tonal range than basic cameras - of course. But how much better? Some sources claim the eye can capture 21 stops of dynamic range, and we know some of our cameras can capture 12 or more stops. This sounds close until you consider a “stop” in photography is a doubling or halving of the exposure.

A clever solution to the issue of extending your tonal range is to blend images of the same scene shot at different exposures (light and dark). This post process has evolved from complicated to relatively simple. Ideally, HDR is shot on a tripod so that your frames are exactly the same. Shoot your scene 3 to 5 times and vary the exposure by a half stop or so, this will leave you with the same image properly exposed, then over and under exposed. The next step is to blend these images, which is now just a few clicks in Lightroom.


HDR Merge in Lightroom

Lightroom makes merging your images easy. Simply select the images you'd like to use, Right Click and choose Photo Merge > HDR Merge


Steve Miller HDR Side by Side

On the left is a single image of five that were shot with differing exposures. On the right is the composite version blended in Lightroom. © 2022 Steve Miller


HDR - Underwater?

There hasn’t been much application for HDR underwater for good reasons. Tripods aren't practical and fish won't hold still and therefore show up as “ghosts” in your image (referred to as ghosting). However, this can now be done with most newer cameras.

Many cameras now have some features to make this easier. If you set your camera to “Burst Shoot” and “EV Bracketing” the camera will rattle off three shots of varying exposure to be blended later in Lightroom.

HDR is an excellent solution to the wide tonal ranges we experience, in particular shooting split-shots. It can solve the problem from blown out highlights (the sky) but it wont solve the problem of color loss at depth. This is a scenario where constant on video lights would work better.


Steve Miller HDR Ghosting

Notice the "ghosting" effect the boats on the bottom right have from their subtle movement between images. © 2022 Steve Miller


The Beauty of HDR is in the Eye of the Beholder

There is what some photographers like to call “Bad HDR” out there. This is when the processing has been heavy-handed and very obvious, even unreal. Descriptions like "Painterly" or "Surreal," etc. are used to describe the presets that are applied in some plug-in HDR programs. The HDR process that is built in to Lightroom is much more subtle and natural looking.

Whether you like this style or not, it is fascinating to see what the process can do compared to a single capture. There is a lot to be learned about exposure and tonal range from experimenting. A great place to start is with sunsets, the detail in the sky is often lost in the capture because the tonal range is so wide. Even if you don't wind up using the image, it's a lesson in how much you can draw out of each file. So next time you're on a dive trip or just hanging out in your backyard at the end of the day, grab your camera, a tripod, and get dynamic!


Steve Miller HDR Backyard Pink Sunset

Don't limit your photographic practice to special places or events, backyard sunsets are the perfect place to start experimenting. © 2022 Steve Miller
