#6420.46.......W-20 with 46mm threads
#6420.............W-20 with 67mm threads
Capture more of the scene by adding the Ikelite W-20 Wide-Angle Conversion lens to your digital still or video housing. Enjoy increased clarity and enhanced color that result from widening your camera lens' angle of coverage and getting closer to your subject.
The Ikelite W-20 can be removed and replaced while underwater for maximum versatility. Includes protective caps, soft pouch, lens cleaning cloth and silicone lubricant.
Available with either 46mm or 67mm threaded mounts. The 46mm threaded lens attaches directly to the
front of many ULTRAcompact digital housing ports. The 67mm threaded lens attaches to compatible
digital housings, video housings and lens port adapters #9306.78 and
Please note that the distance between the camera's lens and the rear element of the wide angle conversion lens can affect both sharpness and angle of coverage. The edges of the image may appear slightly soft in some portion of the camera's zoom range. Results vary by camera model.
|Maximum depth||......60m (200')|
|Weight above water||......630g (1.38 lbs.)|
|Weight under water||......400g (0.88 lbs.)|
|Dimensions||......100mm dia x 60mm L|
|......3.9" dia x 2.4" L|
|Lens Configuration||......4 groups / 5 elements|
|Lens Material||......Optical glass|
|Body Material||......Aluminum alloy|
|Optional Filters||......#6441.42 Tropical Water|
|......#6441.82 Green Water|
|The photo on the left was taken with a Nikon L6 digital camera in an Ikelite housing with the camera lens set at its widest setting of 38mm.||This photo was taken with the Nikon L6 at the same camera to subject distance as the photo on the left. In this photo the Ikelite W-20 wide-angle conversion lens was attached to the port of the Ikelite housing to achieve the wide field of view. Camera lens set at its widest setting of 38mm.|
Click Here for more information on using the W-20 conversion lens with Ikelite video housings.
